Liquid Capsule Filling Machine

A liquid capsule filling machine is a machine that fills liquid materials into empty capsules in different sizes and then seals them for packaging.

Liquid Pill Filling Machine​

A liquid capsule filling machine is also called a liquid capsule filler and liquid capsule filling equipment. This machine fills oil, liquids, or semi-liquids into hard capsules precisely. It seals the capsule body and cap tightly and completes the process with drying. Anxine offers both semi-automatic and fully automatic liquid capsule filling machines to meet your diverse needs.

The liquid filling equipment is divided into semi and fully automatic models. The max output is up to 1,200 capsules per minute. The automatic capsule filling rate could achieve ≥99.5%. Besides, Anxine liquid capsule fillers meet GMP and CE standards for safe and high-quality operation.

Request a Quote Get Catalog

Liquid Capsule Filling Machine for Sale​

Semi-Automatic Liquid Capsule Filling Machine JTJ-L

Semi-Automatic Liquid Capsule Filling Machine JTJ-L

Get precise, reliable control for your liquid and paste capsules using the Semi-Automatic Liquid Capsule Filler JTJ-L. It’s perfect for R&D, pilot runs, and specialty pharmaceutical production.

Automatic Liquid Capsule Filling Machine NJP-500L

Automatic Liquid Capsule Filling Machine NJP-500L

Ready for serious output? The Automatic Liquid Capsule Filling Machine NJP-500L is your answer. It’s built for big production runs, giving you incredible efficiency and consistent quality for your liquid-filled capsules.

Automatic Liquid Capsule Sealing Machine ACF-1200

Automatic Liquid Capsule Sealing Machine ACF-1200

Ensure the ultimate integrity and safety of your liquid-filled capsules with the automatic liquid capsule filler ACF-1200. This vital system perfectly protects contents and guarantees leak-proof pharmaceutical products.

Why Choose Anxine Liquid Capsule Fillers

Precise Dosing

Proper settings of parameters like filling height and vibration frequency keeps the fill weight accurate. The error for each capsule usually stays within ±2% to ±3% of the nominal fill weight.

Low Defect Rate

Under normal adjustment, the machine keeps a low rate of empty capsules, poor cap locking, and capsule damage.

Data Recording

Key process parameters, such as filling speed, vacuum status, and vibration intensity, are easy to record and repeat. This supports batch record filing and product quality traceability.

Applications

The liquid capsule filling equipment uses mechanical sealing to produce capsules that do not leak and crack. It is usually used together with printing, which becomes part of brand anti-counterfeiting. It is also used in the following areas.

Prescription Drugs and OTC Products in the Pharmaceutical Industry

Oil-based liquids, low-melting materials, or moisture-sensitive substances.

Herbal Extracts in the Supplement Sector

Flaxseed oil, plant essential oils, and fat-soluble vitamins.

Botanical Formulations in the Nutrition Industry

Volatile oils, ointment-like materials, or resin ingredients.

How Are Liquid Capsules Made?

If you use an automatic model to make liquid capsules, the whole manufacturing process is completed by the machine itself. If you work with semi-automatic models, some operations require human effort. The automatic liquid filling equipment works as follows.

Capsule Separation and Orientation

The machine feeds empty capsules from a hopper. It separates the capsule cap and body, and then places them into the correct positions in the filling station.

Liquid Preparation

The liquid material enters a dosing system. The system measures a fixed volume of liquid for filling.

Liquid Filling

The dosing nozzle moves above the capsule body. The measured liquid flows into the capsule body with controlled speed and volume.

Capsule Closing

After filling, the capsule cap moves back onto the capsule body. The machine presses the two parts together to close the capsule.

Sealing

A small band of gelatin or sealing solution forms around the joint to prevent leakage.

Capsule Discharge

Finished capsules move out of the machine for the next process.

How to Select a Suitable Liquid Capsule Filler?

An ideal liquid capsule filler should match your needs and improve production efficiency. The selection always depends on the following factors.

Material Viscosity

Some machines handle thin oils, while others can process thick suspensions or semi-liquid materials. Anxine liquid capsule fillers support both liquid and semi-liquid filling.

Flexibility and Adjustment

A good liquid capsule filler should allow easy adjustment of fill volume and capsule size. Machines with quick changeover systems can reduce downtime.

After-sale Support

Reliable after-sales service are also important. Spare parts availability, staff training and technical support keep the machine running smoothly for many years.

Specifications

Models JTJ-L NJP-500L ACF-1200
Output  10,800 capsules/hour 36,000 capsules/hour 1,200 capsules per minute
Capsule Size 00#, 0#, 1#, 2#, 3#, 4# 00# to 5# 00#~2# and safety capsules A~E
Filler Drug Type Liquid material Liquid, oil, suspension Liquid, oil, suspension
Compressed Air 0.03 m³/min, 0.7 MPa 0.06 m³/min 0.3 MPa 0.06 m³/min 0.3 MPa
Overall Dimensions Length: 1,130mm
Width: 700mm
Height: 1,600mm
Weight: 400kg		 Length: 1,350mm
Width: 1,080mm
Height: 1,900mm
Weight: 1,000kg		 Length: 2,300mm
Width: 860mm Height: 2,000 mm
Weight: 900kg

Compatible Upstream & Downstream Machines

Anxine liquid capsule fillers support working with many other types of equipment for production in a line.

Pneumatic Capsule Conveyor – SE Series

Pneumatic Capsule Conveyor – SE Series

Transports all types of capsules with ease. These vacuum conveyors streamline feeding to capsule filling machines.

Pill Counting Machine

Pill Counting Machine

Automate your bottling process with our counting machines. Accurate, reliable, and suitable for pills in all sizes.

Blister Packaging Machine

Blister Packaging Machine

Blister packaging equipment works well with ALU-PVC and ALU-ALU blisters, suitable for packing tablets, capsules, and softgels. It is always applied in pharmaceutical and supplement production.

FAQs on Automatic Capsule Filler​

Answers to common questions about the operation, materials, and maintenance of automatic capsule filling machines.

An automatic liquid capsule filling machine can fill many types of liquids. These include oils, suspensions, and thick liquids used in pharmaceutical or supplement products.
Hard gelatin capsules or HPMC capsules are often used. The capsule material must match the liquid formula.
Stable liquid flow and correct pump settings help maintain accuracy. It requires periodic checks of filled capsules to confirm the filling weight.
Routine maintenance includes checking moving parts, adding lubrication, and inspecting seals and pumps. Regular inspection makes the machine stay in good working condition.
Cleaning is usually needed after each production batch. Regular cleaning helps keep the machine stable and prevents material residue.

US & EU Compliance Requirements for Capsule Filling Machines

If you import a capsule filler or tablet press to the United States or the EU, there are some regulations you must know.

Mandatory US & EU Compliance Requirements for Capsule Fillers & Tablet Presses

If you import a tablet press or capsule filler to the United States or the EU, there are some regulations you must […]

December 2, 2025

Liquid Capsule Filler Resources

Explore helpful resources on liquid capsule filling machines to better understand this equipment.

Popular 8 Types of Liquid Filling Machines & Selection Tips

A liquid filler plays an important role in many supplement, food, and cosmetic factories. It fills each container with the […]

February 17, 2026
